08.99
3
Start-up
Work must not be done on the module when the power supply is on or the motor is turning.
The safety instructions for MASTERDRIVES are to be complied with.
♦ Prerequisites
• The standard converter start-up with "closed-loop speed control" has been completed
• Check the existing board combination
− TSY in conjunction with CU1 (SIMOVERT FC)
− CU2 (SIMOVERT VC) / CUVC (Vector Control)
• Determine the tachometer type
• Select and check the input terminals
• Establish and check the connection to the converter (refer to Figs. 2 and 3)
− SIMOVERT FC
− SIMOVERT VC
• Select the 24 V power supply for the tachometer
− 0.3 A power supply module (option)
− Other 24 V power supplies
"Potential separation" is required for the external supply.
• Check that the screen is grounded at both cable ends and that the board is grounded.
• Set the parameter numbers on the SIMOVERT MASTERDRIVES (refer to the Instruction Manual /
Compendium SIMOVERT converter, Section "Parameter list").
SIMOVERT FC P208, Src Speed(act)
P209, Encoder Pulse #
P090, Brd Slot2
P091, Brd Slot3
SIMOVERT MASTERDRIVES Vector Control (CUVC)
P130, Select MotEncod
P151, Encoder Pulse #
Siemens AG 6SE7087-6CX84-3DB0
Digital tacho-interface Operating Instructions
↔
TSY -X113,-X117 ↔
DTI -X403
↔
DTI -X403
CU2 -X103
CUVC -X103
WARNING
HTL ↔ -X402 DTI
TTL ↔ -X401 DTI
CU1-X107
NOTE
SIMOVERT VC P208, Src Speed(act)
(CU2) P209, Encoder Pulse #
Start-up
(15 V signal level)
(15 V signal level)
(15 V signal level)
21
