08.99
2
Installation, connecting-up
The board is snapped onto a mounting rail. The components must be wired-up by others.
The board provides no protection against direct contact. Protection against direct contact is ensured by
mounting it in an enclosure or in a cabinet.
Screened cables must be used to prevent EMC disturbance. Screens must be connected at X80 and X81.
Perfect functioning of the board cannot be guaranteed if the permissible cable lengths are exceeded (refer to
Figs. 2, 3 and 4). If longer cable lengths are required, please contact your tachometer manufacturer or supplier.
Power- and control cables must be separately routed.
Terminal
Function, information
X401:
TTL tachometer
1
Reference potential (M tachometer)
2
Pulse track A
3
Inverted pulse track A
4
Pulse track B
5
Inverted pulse track B
6
Position track (not evaluated)
7
Inverted position track (not evaluated)
8
Tachometer monitoring track (not evaluated)
9
Inverted tachometer monitoring track
10
5 V tachometer supply
X402:
HTL tachometer
1
Reference potential (M tachometer)
2
Pulse track A
3
Inverted pulse track A
4
Reference potential (M tachometer)
5
Pulse track B
6
Inverted pulse track B
7
Reference potential (M tachometer)
8
Position track (not evaluated)
9
Inverted position track (not evaluated)
10
Reference potential (M tachometer)
11
Tachometer monitoring track (not evaluated)
12
Inverted tachometer monitoring track
13
Reference potential (M tachometer)
14
15 V supply
Table 2.1
Terminals
1)
American Wire Gauge
Siemens AG 6SE7087-6CX84-3DB0
Digital tacho-interface Operating Instructions
NOTES
Installation, connecting-up
Cable cross-section
2
mm
AWG
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
0.5 to 2.5
1)
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
20 to 14
19
