4. Maintenance
4.1 Battery change
The batteries should only be changed outside the Ex-area.
The taking of additional batteries into the Ex-area is not allowed.
Only batteries of Type 6LR61 as per IEC (Refer 7. Technical
Data, p. 29) may be used. The use of alternative types of
batteries is strictly forbidden.
Should the symbol
will need to be changed within the next 1-2 hours.
The unit switches itself automatically off should the battery
voltage be too low.
1 Unscrew back of instrument, remove bottom part and take out
spent battery.
2 Put in new battery correctly (+/-), put on bottom part and
screw tightly.
4.2 Repairs
Should repairs be necessary, then the conditions of ELEX V
must be complied with. We recommend that repairs be carried
out in the manufacturer's factory as it is necessary for the unit to
be checked for technical and safety reasons.
4.3 Cleaning the instrument
The unit should only be cleaned with a moist cloth or sponge.
Detergents or abrasive materials should not be used.
4.4 Regular checks
We recommend that the function and accuracy of the unit be
checked every two years by the manufacturer.
26
be displayed constantly, then the battery
Standard probes
Name
Meas. range Accuracy
Ex-Zone Probe pipe
Immersion /
- 50 to 400°C Class A
2, 1
penetration probe
Surface
- 50 to 400°C Class B
2, 1
probe
Stainless steel
- 50 to 400°C Class A
2, 1, 0
probe
Tank immersion - 50 to 400°C Class A
2, 1, 0
probe
Special probes
Ex-Zone Probe pipe 1
Name
Meas. range Accuracy
Immersion /
- 50 to 400°C Class A
2, 1
penetration probe
Surface
- 50 to 400°C Class B
2, 1
probe
Stainless steel
- 50 to 400°C Class A
2, 1, 0
probe
Tank immersion - 50 to 400°C Class A
2, 1, 0
probe
1 The given values are minimum dimensions, the probes are custom-designed.
2 response time (99%)
5. Probes
t 99 2 Part no.
110 x ø4mm
12s
0628 1232
110 x ø4mm
40s
0628 1932
Surface ø9mm
125 x ø4mm
10s
0628 2232
190 x ø24mm
15s
0628 2432
t 99 2 Part no.
> 50 x > ø4mm 12s
0600 9999
0628 1232
> 50 x > ø4mm 40s
0600 9999
0628 1932
> 50 x > ø4mm 10s
0600 9999
0628 2232
190 x ø24mm
15s
0600 9999
Cable length:
0628 2432
1 to 50m
