RHYTHM DESIGNER RD-8
Specifications
Voices
Number of sounds
16
Type
Analog
Number of simultaneous voices
11 (12 including global accent)
Sound controls
Accent
Level
Bass drum
Level, tone, decay, tuning
Snare drum
Level, tone, snappy
Low, mid, hi conga / low, mid, hi tom
Level, tuning, voice selection
Claves / rim shot
Level, voice selection
Maracas / hand clap
Level, offset, voice selection
Cow bell
Level
Cymbal
Level, tone, decay
Open hat
Level, tone, decay
Closed hat
Level, tone
Select buttons
16 Voice select buttons
Connectivity
Outputs
Phones
1 x ¼" TRS, stereo, 8 Ω impedance
Mono
1 x ¼" TRS, servo-balanced
Voice out
11 x ¼" TS, unbalanced
MIDI In, Out & Thru
3 x 5-pin DIN
Trigger outs
3 x +5 V, 1 ms pulse
Clock in / out
2 x 1/8" TS
USB
Class compliant USB 2.0, type B
Windows 7 or higher
Supported operating systems
Mac OS X 10.6.8 or higher
Volume controls
Master, phones
Return (Input)
1 x ¼" TRS, balanced
Wave Designer
Bus
11 voices, independently assignable
Controls
Attack
-15 to +15 dB, adjustable
Sustain
-24 to +24 dB, adjustable
Send button
On/off, switchable
Sig LED
Red
Analog Filter
Type
State variable, 12 dB slope
Cutoff
10 Hz - 15 kHz, adjustable
Resonance
0 - 10, adjustable
HPF button
LPF / HPF mode, switchable
On button
On / off, switchable
Sync Section
Mode selector
Internal / MIDI / USB / Clock, selectable
Sequencer Section
Edit buttons
Save, copy, erase and dump
Mode buttons
Song, pattern and step
Control
Encoder for data editing
Playback controls
Tap / hold, record, stop, play / pause
Data mode
Tempo / swing / prob / flam, selectable
Auto scroll
On / off, rewind, length (16 / 32 / 48 / 64, selectable), fast forward
Trigger
On / off, repeat division (1 / 2 / 4 / 8, selectable), step repeat, note repeat
Track
Mute / solo, selectable
Step buttons
16 step enter buttons
Settings
Settings
Enter settings mode, use step buttons to select operation.
Autofill
Autofill
Enter autofill selection mode
Songs / Storage
Song mode
Chain any of the 16 songs together for full sets
Pattern / Storage
Capacity
16 songs, 16 patterns each
Pattern mode
Up to 99 iterations per pattern/part
Steps
64 steps
Power Supply
External power adapter
18 V DC, 1000 mA
Power consumption
15 W typical
Environmental
Operating temperature range
5°C to 45°C (41°F to 113°F)
Physical
Dimensions (H x W x D)
77 x 498 x 265 mm (3.0 x 19.6 x 10.4")
Weight
3.0 kg (6.6 lbs)
59
