Components of the system
Horizontal supporting profile.
Pair of runners to cut to length.
Sliding profile for central panel.
Required only for versions with doors of 1800mm and 2400mm width.
Technical information
Vertical downward sliding system.
Door dimensions:
• width 900, 1200, 1800 and 2400 mm;
• height from 480 to 628 mm.
Thickness of the cabinet side:
• 18 and 19/20 mm.
Adjustment:
• height adjustment ± 3 mm.
Fixing supports for the profile.
Tie-rods and cams to fix the
runners.
Bumpers.
Hooks to mount the door onto
the system.
