Maintenance

Instructions for Maintenance

• Always unplug the machine before cleaning.
• The disassembled parts must be reinstalled in place, inspected, and tested
before use.
• If hot water flows out of the drain pump, please wait until it cools down
before opening it, and be careful not to get burned.
• It is recommended to clean the inlet valve filter every month, or when the
error "E1" appears on the display.
• If Auto Dosing does not work properly, please check and clean the
connection between the detergent drawer and the machine.
• Regular cleaning is needed to avoid unnecessary service and prolong the
service life.
Freezing Handling
If the machine is frozen in a place below 0°C, please handle as follows.
1. Wrap the tap with a warm towel to help defrost, and soak the removed
water inlet hose in warm water.
2. Pour warm water into the drum, close the door and let it inactive for 10 minutes,
and then reconnect the water inlet hose to the tap to ensure normal use.
Notes concerning the energy and water
consumption of the washing machine
• The most efficient programs in terms of energy consumption are generally
those that perform at lower temperatures and longer durations.
• Program time as well as energy and water consumption depend on
various factors, such as weight and type of the laundry, chosen functions,
characteristics of the water etc.
• For only slightly or normally soiled laundry, decrease the temperature of
the program, as the device uses less energy this way.
• Use the maximum spin speed available if the laundry will be dried
afterwards, as the remaining moisture content will be lower, which in
turn saves energy during the later drying process. Note, that noise and
remaining moisture content are influenced by the spinning speed: the
higher the spinning speed in the spinning phase, the higher the noise and
the lower the remaining moisture content.
• Load the household washer-dryer up to the maximum capacity of each
program to reduce the energy-and water consumption.

Specifications

Name
Model
Rated Input Power for Wash
Rated Input Power for Spin
Rated Input Power for Heating
Max Power
Drying Power
Rated Voltage
Rated Frequency
Rated Volume
Waterproof Grade
Net Weight/Gross Weight
Dimensions*
* The distance from the rear panel of the machine to its front door
(including the door).
• The program Eco 40-60 and Eco 40-60 Wash+Dry (cupboard) can be used to determine the values of the
energy label according to (EU) 2019/2023.
20
Washer Dryer
WD10001RR4Z
200W
600W
1800W
2000W
1600W
230V~
50 Hz
72L
IPX4
83kg / 89kg
595 (W) × 660 (D) × 850 mm (H)
