Product Overview
Detergent Drawer
Control Panel
Door
Gasket
Drum
Drain Pump Flap
Accessories
User Manual
Water Inlet
×1
Hose ×1
Check all accessories shown in the picture above. If the machine is damaged or the
accessories are missing during transportation, please contact the dealer.
Connecting to the App
1. Scan the QR code to download and install the
Roborock app.
2. Open the app, and tap "Scan to Connect" or "+" to
add an appliance.
3. Follow the instructions in the app to complete the
connection.
4. The WiFi (
) lamp is always on, indicating that the
appliance is connected to the network.
Tap and hold the "Rinse" button for 3 seconds to reset WIFI.
Note:
Transit Bolt
Wrench ×1
Noise Reduction
Cover ×4
Pad x 4
Scan to download the APP
Installation Requirements
Installation Environment
Top Cover
• Place the washing machine on a level, firm, and non-slip surface. Do not
install it on a base or shelf.
• Keep the washing machine in a well-ventilated place away from direct
sunlight and freezing weather.
Power Plug
• The working environment temperature should be 0°C - 40°C.
• Keep the washing machine away from heat sources such as charcoal fires
or gas stoves.
Drain Hose
25mm
Power Supply
• Connect the washing machine to a power supply (230V~/50Hz) which
should be correctly and reliably grounded.
• Make sure the power cord is not pinched by any objects.
Water Supply
• The washing machine requires a water pressure of 0.1MPa to 1.0MPa.
Water pressure lower than 0.1MPa may cause abnormal water inflow. In
this case, the washing machine may not work properly and will display the
prompt [E1].
• Place the washing machine as close to the faucet as possible; Check the
inlet valve and all connections of the faucet for leakage.
• Do not connect the washing machine to a hot water source.
10
25mm
Top: ≥ 25mm
Sides: ≥ 25mm
25mm
Front: ≥ 550mm
Rear: ≥ 50mm
