EUROM Flow Pro 550CW Bedienungsanleitung Seite 16

Technical specifications
Type
Connection voltage
Power consumption
Cap. max.
Class of insulation
Max. supply depth
Max. submersion depth
Max. water temp.
Hose connection
Max. size of
contamination
Residual water (Manual)
Start level (auto-setting)
Stop level (auto-setting)
Noise level Lpa
Cable
Cable length
Dimensions
Weight
Mandatory submersible pump warnings
• The submersible pumps are designed for a maximum water temperature of 40℃.
• Always stand the submersible pump upright when in use.
• Before use, check whether the submersible pump head or suction height do not exceed
the capacity of the submersible pump. The maximum total head in meters from the
submersible pump is 9 meter (Flow Pro 550CW) or 7 meter (Flow Pro 550DW)
• Pollution of the liquid could occur due to leakage of lubricant.
• If the supply cord is damaged, it must be replaced by manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• This appliance is not intended for use by persons with limited physical, sensory or
mental capacities or lacking experience and/or skills, unless such persons are
accompanied and supervised by a person in charge if their safety or they have received
precise instructions on the use of this appliance and have understood the resulting
risks.
• Children must not use the device.
• Supervise children to prevent them from playing with the appliance.
• Cleaning and user maintenance may not be carried out by children.
Flow Pro 550CW
230V – 50Hz
550W
11.000 l/h
IP68
9m
5m
40°C
25mm – 1" – 32mm - 1½"
3mm
5mm
140mm
30mm
≤70dB(A)
H05RN-F 3G 1.00mm²
22x16x31
22x18,5x26
4 + 1 kg
16
Flow Pro 550DW
230V – 50Hz
550W
11.000 l/h
IP68
7m
5m
40°C
25mm – 1" – 32mm - 1½"
16mm
16mm
140mm
30mm
≤70dB(A)
H05RN-F 3G 1.00mm²
21x16x33
22x18,5x28,5
4 + 1 kg
