Sensor Conn C
24 V/DC (moisture) Clarification
- In Room & floor, the
room is the regulator
and the flooring is the
overheating protec-
tion.
- Max. 1 sensor
- Max. 1 sensor
x Humidity control (C)
Moisture/No combined with max. 1
1
moisture temp. sensor, conn. to
input (A).
2
The program can be controlled via a remote control unit connected to the designated terminal blocks. See
wiring diagram. The thermostat switches to the set temperature when the input circuit is closed and when
the input circuit opens the thermostat returns to the previous temperature setting, after the set delay time
where applicable.
Temp. range:
(factory setting)
Set pt. +5 °C » +45 °C
(+22 °C)
OH. +5 °C » +45 °C (+35 °C)
Set pt. +5 °C » +45 °C
(+22 °C)
Low -15 °C » +75 °C (+40 °C)
High +0 °C » +170 °C
(+100 °C)
Max -9 °C » +10 °C (+2 °C)
Min -20 °C » +9 °C (-10 °C)
2
Remote control
x
Vacation, low-temperatu-
re. +5 °C » +20 °C (+12 °C)
Hotel, low temp. +5 °C
» +20 °C (+15 °C), (high
temp. +25 °C), +heat 0-4
hrs (2 hrs)
x
Vacation, low-temperatu-
re. +20 °C » +40 °C (+27 °C)
