Nomenclature; Description Of The Instrument; Power Led; Status-Led - HT EQUITEST Bedienungsanleitung

Input for connection to MASTER
1
instrument via C2050 cable
2
WiFi LED
3

POWER LED

4
STATUS LED
5
Indication of LED status

4. NOMENCLATURE

4.1. DESCRIPTION OF THE INSTRUMENT

Fig. 1 Description of the instrument
10
26
6
Input terminal C1
7
Input terminal C2
8
Input terminal P1
9
P2
Input terminal
Plug cable for connection to mains
supply
EQUITEST
