Technical Data - Sentiotec wave.com4 Touch WC4-B-TC2 Kurzanleitung

QUICK GUIDE FOR GETTING STARTED
This quick guide contains help and information for getting started with your wave.com4
Touch operating unit. For questions about issues are not covered in this quick guide,
refer to the respective user manual.

1. Technical data

Operating voltage:
Power consumption:
Display:
Loudspeakers:
Ambient conditions:
Installation location: The operating unit is not suitable for the sauna interior! Do not install
the operating unit directly next to the sauna doors or showers as the sudden increase in
humidity can cause problems.
Extract
82
Version 05/16
wave.com4 Touch
WC4-B-TC2 / 1-015-611
12–24 V DC (supply via data cable)
max. 5.6 W (standby: max. 1 W)
3.5" TFT (320 x 240 px)
2 x 5 W (8 Ohm)
0 °C–55 °C; maximum 99% relative humidity,
non-condensing
3,5
36
39,5
Ident. no. 1-039-366
EN
92
