4 Bezeichnung des Gerätes
[1]
Auslösetaste
[2]
Nebelaustrittsöffnung
[3]
Anschluss Ladegerät
[4]
Akkupack (Akku, Platine, Sicherung, Stecker)
[5]
Fluidschlauch
[6]
Speakonstecker Akkuverbindung
[7]
Rändelschrauben
[8]
Schnellkupplung für Fluidschlauch
[9]
Fluidtank
[10] Drehregler
[11] LED Akkustandsanzeige
[12] Buchse für Speakonstecker
[13] 3-polige XLR-Buchse
[10]
[11]
[12]
[13]
4 Description of the device
[1]
Start button
[2]
Fog nozzle
[3]
Socket for charger
[4]
Battery pack (Battery, PCB, fuse, connector)
[5]
Fluid tube
[6]
Speakon connector for battery pack
[7]
Knurled screw
[8]
Snap-on connector for fluid tube
[9]
Fluid tank
[10] Rotary knob
[11] LED battery status display
[12] Socket for speakon connector
[13] 3 pin XLR socket
[1]
[2]
[3]
[4]
6
[5]
[6]
[8]
[7]
[9]
