REQUEST FOR UNWOUND METRES, WINDING SPEED, WORKING TIME
To request these data, just send the message
The device will answer with an SMS message containing currently displayed data on RAIN CONTROL 4:
RAIN CONTROL 4 STOP CONTROL
To control RAIN CONTROL 4 Stop, send the message
The device will answer with a short message containing Unwound metres, Winding speed and Working time.
One last SMS message with number 6 will inform of Work cycle end.
MODEM VERSION
To get informations about the modem model send a message with the following codes and wait the answer :
#9#9# request modem model
#9#8# request firmware version
#9#7# request IMSI code
GSM MODEM ERROR CODES DISPLAYED ON RAIN CONTROL 4 LCD
These codes might be displayed in case of faults in the communication between GSM Modem and RAIN CONTROL 4 or be-
tween GSM Modem and telephone operator.
To delete error code, press
ALARM MESSAGES SENT BY RC 4
When the computer detects an anomaly, automatically through the modem, calls the first number programmed on RC4.
To receive the warning message you have to accept the call and automatically will be terminated immediately
and after that will come the sms with the detected alarm message.
In case the first call is not accepted, the modem will call the second number, and consequently the third.
1.
Battery voltage below 8V
2.
Short-circuit on external power supply
3.
Litre counter error
4.
Speed alarm
5.
No pressure
6.
End of work cycle
7.
Error: flowmeter supply
8.
Error: GSM modem power supply
9.
Serious chain slip, shutdown of machine
10.
Controller of chain tightening
11.
SIM card error
12.
Registration number error
13.
Signal error
14.
Error: GSM modem anomaly type 1
15.
Error: GSM modem anomaly type 2
16.
Error: delete all SMS (The RC4 can not delete the messages in the SIM automatically, do this via phone).
17.
Error: send alarm SMS to the phone number.
18.
Error: GSM modem anomaly type 3
19.
Error: GSM modem anomaly type 4
20.
Error - phone # to be contacted not programmed
: #2#2#
to the phone number of inserted SIM card.
1. Unwound metres
2. Winding speed
3. Working time
: #3# #
on RAIN CONTROL 4 .
to the phone number of inserted SIM card.
EN
43
