OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any
commercial DMX controller.

Menu structure

Mode
DMX mode
Automatic mode
Running speed in
automatic mode
Individual brightness
Dimmer
In and out fading
Strobe effect
Behaviour in case of
missing DMX signal
Slave mode
Key lock
IR remote control
Firmware version

Stand-alone mode

Automatic mode
In automatic mode, 4 show programs are available that run at an adjustable speed.
1 Press the MENU button so many times until AUTO is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired show program (01-04). Confirm with the
ENTER button.
2 Press the MENU button so many times until SPEED is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from 01 (slow) to 09
(fast). Confirm with the ENTER button.
Individual brightness
In the mode COLOR each UV LED can be individually adjusted for brightness. The device will constantly
emit the brightness.
1 Press the MENU so many times until COLOR is indicated in the display. Confirm with the ENTER button.
2 Now the display indicates UV for UV LED and the corresponding brightness value. Use the buttons UP
and DOWN to adjust the desired brightness.
3 Confirm with the ENTER button.
Display
4-CH
ADDR:001-512
ADDR:001-512
DMX 2-CH
ADDR:001-512
1-CH
AUTO
SPEED
COLOR UV: 000-255
DIMMING
FADING
FLASH
Blackout
DMX lost
SLAVE SLAVE MODE
PASSCODE
INFRARED
V1.0
21/28
4-channel mode and start address
2-channel mode and start address
1-channel mode and start address
01-04 Auto program
Program running speed
01-09
slow > fast
UV 0-100%
Total brightness
01-99
dark > bright
Fade-in and fade-out of the UV LEDs
00-99
slow > fast
00-99 Strobe effect slow > fast
LEDs go off
Hold Spot holds the last received signal
Full All LEDs 100% on
Auto Pre-selected static color 01-04
Slave mode
ON Key lock on
OFF Key lock off
ON IR remote control on
OFF IR remote control off
V1.0 Firmware version number
Function
00135434, Version 1.0
