DESCRIPTION OF THE DEVICE
Features
LED color changing bar with TILT movement and 8 W QCLs
• Stepless vertical movement via control panel or DMX
• Equipped with 6 quadcolor LEDs in the colors red, green, blue and white
• 6, 8, 12 or 30 DMX channels selectable
• Each LED can be controlled individually
• Hanging as well as standing installation possible
• Functions: RGBW color mixture, color presets, 11 preset color temperatures, automatic color change, built-
in programs, dimmer, strobe effect, sound-control, Master/Slave operation
• Dimmer speed (step response) adjustable
• Automatic position correction
• Adjustable microphone sensitivity via Control Board
• DMX-controlled operation or stand-alone operation with Master/Slave function
• Comfortable addressing and setting via Control Board with LCD display and four operating buttons
• Switch-mode power supply, automatic power supply adaption between 100 and 240 Volts without power
selector
• Power connection via Neutrik PowerCon jack and included power cable
• Feed-through output allows to power another device
• After every 8 devices the fixtures must have a renewed connection with the power mains
• DMX control via every standard DMX controller
Overview
1
2
3
4
(13) Mounting bracket
(14) Fuseholder
(15) Rubber foot
5
6
7
8
9
11
12
13
14
10
24/36
(1) Housing
(2) LED
(3) Mode button
(4) Enter button
(5) Display
(6) Up button
(7) Down button
(8) DMX-In socket
(9) DMX-Out
socket
(10) Power input
15
(11) Safety eyelet
(12) Power output
00074698, Version 1.0
