Spezifikationen
epc8101Voltage
epc8101Frequency
epc8101Pow erFactor
epc8101Pangle
epc8101Pow erApparent
epc8101Pow erReactive
epc8101AbsEnergyReactive
epc8101AbsEnergyActiveResetta
ble
epc8101AbsEnergyReactiveReset
table
epc8101ResetTime
epc8101Forw EnergyActive
epc8101Forw EnergyReactive
epc8101Forw EnergyActiveResett
able
epc8101Forw EnergyReactiveRes
ettable
epc8101RevEnergyActive
epc8101RevEnergyReactive
epc8101RevEnergyActiveResetta
ble
epc8101RevEnergyReactiveResett
able
epc8101ResidualCurrent
epc8101LineSensorName
epc8101OVPIndex
epc8101OVPStatus
epc8101CPUSensorVsystem
epc8101CPUSensorVaux
epc8101CPUSensorVmain
epc8101CPUSensorTcpu
epc8101NTPTimeValid
epc8101NTPUnixTime
Expert Power Control 8101
.89.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.89.1.5.1.2.1.7.x
Frequency of Pow er Channel
.89.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.89.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.89.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.89.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.89.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.89.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.89.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.89.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.89.1.5.1.2.1.16.x
Forw ard Active Energy counter.
.89.1.5.1.2.1.17.x
Forw ard Reactive Energy counter.
.89.1.5.1.2.1.18.x
Resettable Forw ard Active Energy counter.
.89.1.5.1.2.1.19.x
Resettable Forw ard Reactive Energy counter.
.89.1.5.1.2.1.20.x
Reverse Active Energy counter.
.89.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.89.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.89.1.5.1.2.1.23.x
Resettable Reverse Reactive Energy counter.
.89.1.5.1.2.1.24.x
Actual Residual Current on Pow er Channel. According Type A IEC
60755. Only visible on models that support this feature.
.89.1.5.1.2.1.100.x
A textual string containing name of a Line Sensor
.89.1.5.2.1.1.x
None
.89.1.5.2.1.2.x
show s the status of the built-in Overvoltage Protection
.89.1.5.14.1.0
System Voltage on CPU Board
.89.1.5.14.2.0
Auxiliary Voltage on CPU Board
.89.1.5.14.3.0
Main Voltage on CPU Board
.89.1.5.14.4.0
Temperature on CPU Board
.89.1.5.15.1.0
Show if valid Time is received
.89.1.5.15.2.0
show received NTP time as unixtime (secs since 1 January 1970)
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Unsigned32 RO
OCTETS RW
Integer32 RO
INTEGER RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
INTEGER RO
Unsigned32 RO
