Dräger Polytron 5200 CAT Montageanweisung Seite 5

PointGard 2200 CAT
G
3-core cable
0,2 mm² - 2,5 mm²
AWG: 24 - 14
max. 30 m / 100 feet
twist cable
7
B2
3-core field wiring
S
1a
1b
2
3a
3b
I
1a
1a
Brown
1b
1b
Yellow
2
2
3a
3a Black
3b
3b
≥ 8 LB IN/ ≥ 0.7 Nm
≥ 44 LB IN/ ≥ 5 Nm
2x
Install bridges
1a 1b 3a 3b
E
Junction Box Ex d
A2
≥
5
≥
266 LB IN /
A1
1a 1b 2 3a 3b
B1
Y
Use double ferrules
C
≥
30 Nm
I
