Dräger Polytron 5200 CAT Montageanweisung Seite 4

Polytron 5200 / 8200 CAT
Polytron 5310 / 8310 IR
Polytron 5700 / 8700 IR
Polytron 5720 / 8720 IR
Without relay:
x
1a 1b 2 3a 3b
G1
G
5-core cable
0,2 mm² - 2,5 mm²
AWG: 24 - 14
Install harness X
2x
F1
5-core field wiring
1a
1a
1b
1b
2
2
3a
3a
3b
3b
Mount spacer
D
Junction Box Ex d
1a 1b 2 3a 3b
Y
DD/DQ sensor only,
twist cable.
7
≥ 44 LB IN/ ≥ 5 Nm
B2
A2
A2a
≥
5
≥ ≥
266 LB IN / 30 Nm
A1
Without relay:
B1
≥ 8 LB IN/ ≥ 0.7 Nm
E
