KIKKA BOO i-TOUR Gebrauchsanweisung Seite 7

IMPORTANT! KEEP FOR FUTURE REFERENCE!
EN
READ CAREFULLY!
Facing forwards (100-150cm) Installation
Store 5-point harness Install the child safety seat with ISOFIX+adult safety-belt. If you don't have ISOFIX, please ignore this step. Install the child safety seat with adult safety-belt only.
Pull out the belt from the belt ALR (Automatic Locking Retractor ). The shoulder belt through the same side of Belt Guidance (14) on headrest, then pull the shoulder belt and lap belt
together through the other Belt Guidance (16) on the seat base.
Lock the tip of the buckle into the vehicle seat buckle with a clicking sound. Follow the direction of arrow to tighten belt, and put redundant belt into ALR. Shake the child safety seat to
make sure it is securely attached.
NOTICE! Keep the shoulder belt at the position of belt guidance between the outside of the neck and shoulder (in the middle of point a and point b).
WARNING! The adult safety-belt must not be twisted or have their places changed over.
NOTICE! The importance of ensuring that any lap belt is worn low down, so that the pelvis is firmly engaged, shall be stressed.TIP!The shoulder belt section must run diagonally back-
ward. You can adjust the course of the belt with your vehicle's ALR on both sides.
8. CLEANING AND MAINTENANCE
SEAT COVER
Only use authentic i-Tour Seat Cover (4). The Seat Cover (4) is an integral part of the child safety seat and is key to ensure the trouble-free functionality of the system.
The Shoulder Pads (5)Seat Cover (4) and newborn cushion(15) can be washed in luke warm soapy water. Remove all foam parts from the top and bottom sections before washing. These
must not be washed.
HARNESS BUCKLE
1.Open the Harness Buckle (7) as shown. Remove Crotch Pad (8).
2.Lift the seat cover, pull down Harness Buckle (7) across Seat Cover (4).
3.Rotate the metal plate on crotch straps from (F) by 90° vertically.
Slide the metal plate through the harness slot in the way (E) lies in horizontal position, then Harness Buckle (7) can take out from slot (D).
To re-install Harness Buckle (7) follow the steps in reverse order, until the metal plate is hooked into the harness slot.Thread the Harness Buckle (7) through the Crotch Pad (8) on the
cover. Make sure the metal plate under slot (F) when you are using.
CAUTION! Tug hard on the crotch strap to make sure that it is secure in the seat shell.
To ensure the safety of your child, it is absolutely essential that the Harness Buckle (7) continues to function correctly. Harness Buckle (7) malfunctions are usually caused by a build-up of
soiling or by external objects:
When you press the Red Release Button (18), it takes a long time for the Buckle Tongues(17) to be ejected.
The Buckle Tongues(17) no longer engage when you try to push them in, they pop out again).
The Buckle Tongues(17) engage without a clicking sound.
The Buckle Tongues(17) are difficult to push in (you feel a certain amount of resistance).
The Buckle Tongues(17) only opens if extreme force is applied.
Remedy: Soak the harness buckle in warm water containing washing-up liquid for at least an hour. Rinse the buckle thoroughly and dry it.
The plastic parts and the harnesses can be cleaned with soapy water. Do not use any caustic cleaning agents (such as solvents).
Produced for Kikka Group Ltd., Vasil Levski 121, Plovdiv, Bulgaria. Made in China.
Complies with ECE R129.
ENGLISH
