Before carrying
maintenance activities,
extractor is disconnected from the mains.
To carry out cleaning and maintenance, follow
the Safety Instructions.
Fire risk exists in case that cleaning does not
take place according to the instructions.
Filter cleaning
To withdraw the filters from their locations
release the anchoring points. Clean the filter,
either by putting it in the dishwasher (see
notes) or leaving it standing in hot water to
simplify the removal of grease or, if wished, by
means of special sprays (protecting the non
metallic parts). Once clean, leave it to dry.
To replace the filters, proceed in the reverse
way to their removal. Make sure that the filter
latch is securely attached to the housing to
prevent untimely drops of the filters.
Attention: the cooker hood will not work until
the main filter was reinstalled.
Notes: cleaning in the dishwasher with
aggressive detergents
surface of metallic parts, without this affecting
its gas retaining properties.
N.B. The filter must be cleaned at least once a
month depending on how often the extractor
is used. It must be remembered that grease is
Electrical characteristics:
REFER TO RATING PLATE
This appliance has been designed, tested and
manufactured according to:
• Safety: EN/IEC 60335-1; EN/IEC 60335-
2-31, EN/IEC 62233.
In order to fix the cooker hood to the kitchen
unit you can choose one of these two
possibilities (fig.3):
22
out any cleaning
ensure that
may blacken
or deposited in the extractor when cooking,
the whether it is switched on or not.
Cleaning of the extractor body
The use of warm (40ºC approx.) soapy water
is recommended. A cloth moistened in this
water is used for cleaning the extractor, paying
special attention to the grids. Afterwards, dry it
using a lint-free cloth.
Note:
• Never use metallic scouring pads or
abrasive products that could damage the
surface.
• Do not use scrapers with metallic surfaces
such as knives, scissors etc.
Activated charcoal filter
• To install the charcoal filter, disassemble
the lid, introduce the filter in the position
provided and reassemble the lid.
• The carbon filter lasts from three to six
months depending on the particular
conditions of use.
• The activated carbon filter can neither be
washed nor regenerated. Once it is
the
exhausted, it must be changed.
• To replace the exhausted filter with a new
one, we will make in the same way that in
its assembly, previously extracting the
spent filter.
• A reduction in the extraction flow rate may
be observed in the hood with the
installation of carbon filters.
• Performance: EN/IEC 61591; ISO 5167-1;
ISO 5167-3; ISO 5168; EN/IEC 60704-1;
EN/IEC 60704-2-13; EN/IEC 60704-3;
ISO 3741; EN 50564/IEC 62301.
• EMC: EN 55014-1 / CISPR 14-1; EN
55014-2 / CISPR 14-2; EN/IEC 61000-3-
2; EN/IEC 61000-3-3.
a) To the upper part of the furniture, figure 3
specify where the position of the holes
denominated
