Qty
Pos.
Cod.
1
1
Z67000003
2
2
Z78270121
3
2
ZAD070120
4
1
Z7909A048
5
1
ZAD070164
6
1
ZAD070163
7
1
ZAD080534
8
2
Z1510A013
9
1
Z45952902
10
1
Z78160002
11
1
Z63640070
12
1
Z7407A040
13
1
Z78165265
14
1
Z7907A043
15
2
Z1908A051
16
1
Z70500005
17
4
Z7408A003
18
1
ZAD080522
19
1
ZAD080521
20
2
Z7907A044
21
1
Z70510001
22
4
Z7407A031
23
1
Z7909A044
24
1
Z7408A054
25
1
Z7309A050
26
1
Z78012250
Figure A: Machine Assembly
Description
MAIN SWITCH
FAN 12Vdc 120x120x38
INVERTER BOARD
FLAT CABLE 4 CONNECTOR
INPUT BOARD SLAVE
INPUT BOARD MASTER
CONTROL BOARD
TRASFORMER OUT
KNOB
OUTPUT DINSE
REMOTE CONNECTOR 7 PIN
FRONT PANEL
TORCH CONNECTOR EASYFIT
FLAT CABLE CONTROL
OUTPUT INDUCTOR
SOLENOIDE VALVE SMC EVT317-6DO-02F-Q
INTERNAL SUPPORT METAL
OUTPUT BOARD MASTER
OUTPUT BOARD SLAVE
FLAT CABLE INPUT
PRESSURE REGULATOR
PLASTIC SUPPORT
INPUT CORD
EXTERNAL CASE
ALUMINUM COVER RAL 7037
HANDLE
3
PC 130 - 2010
