Anhang C: MIDI
13.4.19 Parameter change (Function call: effect)
Reception
If [Parameter change RX] is ON and the [Rx CH] matches the Device
Number included in the SUB STATUS, these messages are received. If [Pa-
rameter change ECHO] is ON, these messages are echoed.
When this is received, the corresponding effect's function activates (de-
pending on the effect type).
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0001nnnn 1n
GROUP ID 00111110 3E
MODEL ID 01111111 7F
ADDRESS 00010010 12
0000ffff 0f
00000000 00
0ppppppp pp
DATA 00000000 00
0eeeeeee ee
EOX 11110111 F7
function
Freeze Play button
Freeze Record button
Auto Pan 5.1 Trigger Button
Auto Pan 5.1 Reset Button
• This does not activate when the effect type is different.
13.4.20 Parameter Change
Reception
If [Parameter change RX] is ON and the [Rx CH] matches the Device
Number included in the SUB STATUS, these messages are received. If [Pa-
rameter change ECHO] is ON, these messages are echoed.
The Scene memory Sort table is updated as soon as the messages are re-
ceived.
If Studio Manager performs a scene memory sort, it will transmit this data
to the 02R96.
Transmission
When scene memory sort is executed on the 02R96, the memory sort table
will be transmitted to Studio Manager.
Studio Manager will sort the memories according to this data.
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0001nnnn 1n
GROUP ID 00111110 3E
MODEL ID 00001011 0B
ADDRESS 00010011 13
0000ffff 0f
DATA 0ddddddd ds
:
:
0ddddddd de
EOX 11110111 F7
8-7 conversion is performed on the data area in the same way as for bulk.
13.4.21 Parameter Request
Reception
This is received if [Parameter change RX] is ON and the [Rx CH] matches
the device number included in the SUB STATUS.
This is echoed if [Parameter change ECHO] is ON.
Sort table data is transmitted as Parameter Change messages on the [Rx
CH] channel.
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0011nnnn 3n
GROUP ID 00111110 3E
MODEL ID 00001011 0B
ADDRESS 00010011 13
0000ffff 0f
EOX 11110111 F7
02R96 Version 2—Bedienungsanleitung
System exclusive message
Manufacture's ID number (YAMAHA)
n=0-15 (Device number=MIDI Channel)
MODEL ID (digital mixer)
Universal
Function call Effect Event
function
Release:0, Press:1
Effect number (0:Effect1 - 3:Effect4)
End of exclusive
channel
0x00 0:Effect1 - 3:Effect4
0x01 0:Effect1 - 3:Effect4
0x02 0:Effect1 - 3:Effect4
0x03 0:Effect1 - 3:Effect4
(Sort table data)
System exclusive message
Manufacture's ID number (YAMAHA)
n=0-15 (Device number=MIDI Channel)
MODEL ID (digital mixer)
02R96
Library sort table
Library type
Data
Data
End of exclusive
(Sort table data)
System exclusive message
Manufacture's ID number (YAMAHA)
n=0-15 (Device number=MIDI Channel)
MODEL ID (digital mixer)
02R96
Library sort table
Library type
End of exclusive
13.4.22 Parameter change (Function call: attribute)
Reception
This is received if [Parameter change RX] is ON and the [Rx CH] matches
the device number included in the SUB STATUS.
This is echoed if [Parameter change ECHO] is ON.
When this is received, the attribute of the specified memory/library will be
changed.
Transmission
In response to a request, a Parameter Change message will be transmitted
on the [Rx CH].
If [Parameter change ECHO] is ON, this message will be retransmitted
without change.
System exclusive message
STATUS 11110000 F0
Manufacture's ID number (YAMAHA)
ID No. 01000011 43
n=0-15 (Device number=MIDI Channel)
SUB STATUS 0001nnnn 1n
MODEL ID (digital mixer)
GROUP ID 00111110 3E
Universal
MODEL ID 01111111 7F
Function call
ADDRESS 00010100 14
attribute
0000ffff 0f
number High
0mmmmmmm mh
number Low
0mmmmmmm ml
attribute (protect:0x0001,
DATA 0ttttttt th
normal:0x0000)
0ttttttt tl
End of exclusive
EOX 11110111 F7
function
SCENE LIB ATTRIBUTE
AUTOMIX LIB ATTRIBUTE
13.4.23 Parameter request (Function call: attribute)
Reception
This is received if [Parameter change RX] is ON and the [Rx CH] matches
the device number included in the SUB STATUS. This is echoed if [Param-
eter change ECHO] is ON.
When this is received, a Parameter Change message will be transmitted on
the [Rx CH].
Refer to the above table for the Functions and Numbers.
System exclusive message
STATUS 11110000 F0
Manufacture's ID number (YAMAHA)
ID No. 01000011 43
n=0-15 (Device number=MIDI Channel)
SUB STATUS 0011nnnn 3n
MODEL ID (digital mixer)
GROUP ID 00111110 3E
Universal
MODEL ID 01111111 7F
Function call
ADDRESS 00010100 14
0000ffff 0f
number High
ATTRIBUTE 0mmmmmmm mh
number Low
0mmmmmmm ml
End of exclusive
EOX 11110111 F7
13.4.24 Parameter change
Reception
This is received if [Parameter change RX] is ON and the [Rx CH] matches
the device number included in the SUB STATUS. This is echoed if [Param-
eter change ECHO] is ON.
When this is received, the patch link data of the specified scene will be
modified.
Transmission
In response to a request, a Parameter Change message will be transmitted
on the [Rx CH].
If [Parameter change ECHO] is ON, this message will be retransmitted
without change.
System exclusive message
STATUS 11110000 F0
Manufacture's ID number (YAMAHA)
ID No. 01000011 43
n=0-15 (Device number=MIDI Channel)
SUB STATUS 0001nnnn 1n
MODEL ID (digital mixer)
GROUP ID 00111110 3E
Universal
MODEL ID 01111111 7F
Function call
ADDRESS 00010100 14
link
0010ffff 2f
number High
0mmmmmmm mh
number Low
0mmmmmmm ml
number
0x00 0-99 (0:response only)
0x0B 1-16
(Function call: link)
