dirna Bergstrom bycool green COMPACT 3.0 Montageanweisungen Seite 21

COMPACT 3.0
To place the front (at the previous mentioned)
11
spigots with (1) washer M6 wide wing and
(1) nut M6 in each spigot. To tight nuts til the
rubber ducting til run into the upper rubber of
the unit.
IMPORTANT: The rubber ducting must
being run into the upper rubber of the unit
to avoid air leaks.
11
EPDM
Gasket
Cabin roof
Upholstey
Tighten nut mentioned under point 10a until it
12
touches upper surface of front.
12
EPDM
Gasket
Cabin roof
Upholstey
Unit base
D
Nut M6
Unit base
Nut M6 (10a)
Nut M6
Air conditioning for vehicles
Rubber ductings
Rubber ductings
21
Foam Gasket
front with louvers
Foam Gasket
front with louvers
ES
EN
