Dual 721 Bedienungsanleitung Seite 13

Fig. 21
Fig. 22
Tonarmlift
Ihe HIF) Plattenspieler ist mit eimam erschut
terungsfrei_bedienbaren, in beiden Bewe
gungsrichtungen siliconbedampften Tonatm:
lift augestattet. Damit kann der Tonarm
sanfter auf jede gewunschte Stelle der Schall
platte aufgesetzt werden, als es von Hand
moglich ware Der Steuerhebel des Tonarm
liftes (16) hat zwei Stellungen
Zwahlen
der Tonarm ist van der Schaliplatte abge-
oben
der Tonarm ist auf die Schaliplatte abge
senkt
When replacing a cartridge recheck setting of
vertical tracking angle After mounting a
cartridge balance tonearm page 20, set stylus
ppressure page 22 and compensate for skating
force page 24
Before adjusting tonearm height (distance
between the mounting level of the cartridge
and stylus tip) disconnect the hine plug, Then
place 3 30:cm record on the platter and
lower the stylus tip of the cartridge on the
runout groove of the record Now check the
horizontal position of the tonearm. The
tonearm setting 4s correct when the tonearm
tube #6 paralleled to the record. The vertical
tracking control enables the user to adjust
tonearm height within the range of approx
Bmm
Alter correction secure knurled wheel by
turning the locking lever fully clockwise thus
avoiding accidental shifting
For swinging back the tonearm to its original
position on the resting post use the cue
Control cue control in ¥ position, place
back tonearm by hand t0 ITS resting post and
lower it with cue control in position
Connect the unit to the power line and start
HL o n c e with its tonearm locked. Just move
the operating switch to start" This it
sure that the automatic shut-off mechanism
will be n the correct position
Cue Control
Your turntable is equipped with a shock-free
ue control siicone damped in both drections,
Thus, the tonearm can be lowered to any de
sired point on the record more gently than
by hand
The lever of the cue contro! (16) has wo
positions
