Step 1:
Set Supply Voltage
T urn on the power supply and set the voltage to +3.3 V DC

Turn the power supply OFF

Step 2:
Connect Sensor to Power Supply
C onnect power supply (–) to connector pin 3

C onnect power supply (+) to connector pin 1 (UB1)

