Installing AXKID MODUKID BASE in the
vehicle
Attach and adjust the front brace (A) to its innermost position by pulling the front brace release knob (B) and pushing the front
1
brace into the AXKID MODUKID BASE. Fold out the support leg (M) until the support leg installation indicator (J) turns green.
When the support leg is unfolded the support leg installation buzzer (O) will start beeping. The beeping will stop after correct
installation is completed.
2
Pull the ISOFIX knob (I) and extend the ISOFIX arm (F) to a suitable position (i-iv). Repeat step for both ISOFIX arms.
3
Attach the ISOFIX arms (F) to the vehicle ISOFIX connection points in the correct vehicle seat position (see Allowed and
disallowed positioning of the AXKID MODUKID BASE, p14). Make sure that the ISOFIX installation indicator (G) shows green.
Extend the front brace (A) towards the vehicle seat by pulling the front brace release knob (B) and pushing the front brace (A)
4
towards the vehicle seat, and then release the front brace release knob (B). Make sure to apply as much pressure as possible
and that the front brace release knob (B) clicks into position.
Pull the support leg knob (K) and pull the lower part of the support leg (M) downwards until the support leg foot (N) is in
5
contact with the vehicle floor. Let go of the support leg knob (K) and lift the AXKID MODUKID BASE upwards to further
extend the support leg (M) until you hear a click. The support leg (M) should now be locked and firmly pressed against the
vehicle floor and the sound from the support leg installation buzzer (O) have stopped.
To install AXKID MODUKID INFANT 2 or AXKID ENVIROKID on the AXKID MODUKID BASE, pull the seat release handle (E)
6
to its extended position (see F6). Place the car seat in position on top of the AXKID MODUKID BASE and push the car seat
down into the MODUKID BASE until the seat release handle (E) clicks into locked position and the seat attachment indicator
(D) shows green.
