dirna Bergstrom bycool green COMPACT 2.0 Montageanweisungen Seite 15

COMPACT 2.0
Mount the front air input grille before starting
!
assembly.
Dismantle sun hatch, fastening elements and
1
hand over to client.
Remove residual glue substance of the roof
2
upper surface before glueing EPDM gasket.
For some models, upholstery does not leave
3
enough space to introduce fastening supports.
If it is the case, cut according to measures
indicated on photo.
All manuals and user guides at all-guides.com
15
Air conditioning for vehicles
1
2
3
EN ES
