9. BLUETOOTH / WIFI CONNECTION

RJ11 connector
TPM7-POOL is a model to which an external Tpool-B or Tpool-W communications
module can be optionally connected via the RJ11 connector. As external communication
modules, the range of the equipment is considerably improved.

10. TECHNICAL SPECIFICATIONS

Power supply
Pump output
Lighting output
Auxiliary relay
(free voltage)
Max. terminal
cross-section
(power / control)
Temperature
Directives
20
Distribuido por Adajusa
TPOOL-B
230VAC / 5A | 12 VAC / 50W
| - 2016 -
|
ON
TPM7 POOL
1
ON
OFF
OFF
ON
AUX
2
push to push>4s
reset man
OFF
230VAC - 50/60Hz
14A, 230VAC
| 12VAC / 100W |
250V/5A max.
4mm2 / 2,5mm2
-10º...+55º C
| D.C. 2014 / 30 / CE
D.C. 2014 / 35 / UE
| ROHS | EN61558
12VAC / 300W
| EMC |
| C.E.
|
