1. MODULE OVERVIEW

B
C
A
ON
5
1
OFF
ON
6
2
push to
reset
OFF
7
F
Terminals
A. Tranformer current input (In>14A)
B. Heating pump relay input and/or
external temperature sensor
C. Lighting control input
D. Filtration control input
E. Auxiliary relay output (free potential)
F. Lighting supply output
G. Pump supply output
H. Power supply 230V input
12
Distribuido por Adajusa
D E
ON
OFF
AUX
push>4s
man
G H
1
2
73
mm
3
4
Pilots lights
1. Lighting program.
2. Auxiliary output
3. Current time
4. Alarm / Calibration
5. Filtration program 1 (ON/OFF)
6. Filtration program 2 (ON/OFF)
7. Pump running
53
mm
91
mm
