BabyGo Move 360 Montageanleitung Seite 20

INSTALLATION
REARWARD FACING + ISOFIX
Making rearward facing position by using ISOFIX attachment + Support leg (suitable for
children height from 40-105cm)
25
DO NOT place rear-facing child seat on front seat
with airbag. IMPORTANT-DO NOT use forward facing
before the child's age exceeds 15 months.
DEATH OR SERIOUS INJURY can occur.
2.
Press the supporting leg adjustment but-
ton by your hand and pull the Support leg
down until it touches the car surface
3.
Place the child in car seat and secure with
5-point seat belt system
Attention: When the supporting leg touches
the car surface, the support leg indicator
must be all green (as shown in the figure).
38
1.
When installing the child safety seat in the
forward facing position, take the Support leg
out from the bottom of the seat according to method
4-10, and then rotate the seat to the rearward position
according to method 4-6 (see Figure 25). Then accor-
ding to method 4-9, Installing the ISOFIX attachment
to the car seat firmly.
Attention! If your child's height is less than
105cm, pls use rearward facing.
FORWARD FACING + ISOFIX + 5 POINT BELT
Installing the child safety seat forward facing position by using ISOFIX attachment + Sup-
port leg (suitable for children height from 76-105cm)
27
2.
Press the Support leg adjustment button
by your hand and pull the Support leg
down until it touches the car surface
3.
Place the child in car seat and secure with
5-point seat belt system
Attention: When the supporting leg touches
the car surface, the support leg indicator
must be all green (as shown in the figure).
26
MOVE 360
1.
When installing the child safety seat in the
forward facing position, take the Support leg
out from the bottom of the seat according to method
4-10, and then rotate the seat to the forward position
according to method 4-6 (see Figure27). Then accor-
ding to method 4-9, Installing the ISOFIX attachment
to the car seat firmly.
DE
EN
FR
NL
28
39
