Optional accessory:
SensoLite 310
Protection class IP 66
26
35
34
33
26 All-round marking groove
27 Receiver field for laser beam
28 SpotLite Marking LED
29 Vial
30 Fastening screw for levelling staffs
31 Universal mount
32 Binding screw / loudspeaker (rear side)
33 Battery compartment (rear side)
34 Control panel
35 LC-Displays (front and rear side)
Display Precision range
36
Free-hand range
Note: The laser receiver has two tolerance settings: Precision and free-hand setting.
Revolution / Revolution Green
27 28 29
30
31
32
/
36
37
38
39
40
41
42
43
37 Hand receiver above laser level
38 Precisely on laser level
39 Hand receiver below laser level
40 Volume indicator
41 Low battery indicator
42 Switch on /
Hand receiver mode /
Switch: Precision range /
Free-hand range
Switch off:
press button 3 seconds
43 Volume adjustment
