Revolution / Revolution Green

Rotary mode

The following speeds can be set using the rotary button:
750, 350, 0 rpm
Spot mode
You access spot mode by pressing the rotary button
repeatedly until the laser stops rotating. The laser can
then be positioned exactly at the measuring point by
means of the direction buttons.

Scan mode

The scan button can be used to activate and set a light-
intensive segment in 4 different widths. You position the
segment via the direction buttons.
Revolution Green
The distance at which a laser is visible to the naked eye depends on its colour i.e.
wavelength. This is because of the human eye's physiology – green appears brighter to
us than red. Depending on ambient light, green lasers are therefore many times more
visible than red lasers; in indoor areas this is as much as 12 times brighter. This permits
applications on dark surfaces, over longer distances and work in very bright ambient
light. A red laser with a 635 nm wavelength is used as a reference value for brightness
differentiation.
In contrast to red lasers, green laser light can only be produced indirectly. This is a source
of potential characteristic fluctuations:
• The optimal operating temperature is 20°C. Outside of the operating temperature
range of 0 ... 45°C green lasers become darker. IMPORTANT: Allow the unit enough
time to adapt to the ambient temperature before switching the unit on.
• Laser brightness may vary somewhat from one unit to another. This is a natural pheno-
mena and excluded from warranty claims.
• Green Laser will only work with certain Receivers. The maximum range of the Receiver
is shorter, please refer to technical details.
