Only mobile oven rack: Select the
appropriate front panel. With the
Combi-Duo kit for mobile oven
racks, the front panel must be fitted
with the positioning aid.
Bottom unit right hand door: Re-
move the cover of the door retain-
ing plate and loosen the screw.
Bottom unit left hand door: There
is no need to attach it to the door
retaining plate.
11. Push the front panel (1) to the right (2)
to the right side panel [
>
Ensure that the lug on the front
panel is inserted in the opening of
the right side panel (2).
>
Mount the front panel on the left (3)
on the two stud bolts with two cap
nuts (4).
>
Only mobile oven racks (bottom
unit right hinged): Insert the tab
into the side opening of the front
panel. The O-part must point in the
direction of the door retaining
plate.
Fix the front panel with the tab in-
serted on the door retaining plate
with the loosened screw.
Tighten the screw to 33 Nm.
12. Screw the right side panel to the front
panel [ Figure
screw until the gap between the side
panel and the front panel is closed.
13. Insert the left side panel. The side
panel is pulled around the edge to the
rear side of the frame. Fix the left side
panel on the rear side of the Combi-
Duo frame with 1 screw
[ Figure 12].
16 / 100
Figure 10].
11]. Tighten the
80.51.370_iCombiPro-iCombiClassic_CD-E_IM_EU-west
14. If an Ethernet cable is to be connected
to the top unit, connect the cable be-
fore assembling the exhaust pipe for
better accessibility.
15. Place the heat shield cover on the bot-
tom part of the exhaust pipe so that
the connections on the rear side of the
top unit are protected from heat
[ Figure 13].
16. Place the exhaust pipe on the air vents
of the bottom unit [
17. Place the holder on the air vents of the
top unit and the exhaust pipe
[ Figure 15].
Turn the door handle of the bottom unit
1. Disassemble the door handle of the
bottom unit: Remove the plastic cover
of the door lock on the inner side of
the door, by sliding the cover towards
the inner side of the door and taking it
out.
2. Loosen the screws of the door handle
with a 5 mm Allen key.
3. Pull the door handle off, turn it 180
degrees and reattach the door handle.
4. Apply the plastic cover.
6

Remote control

With the Combi-Duo tower, you have the
option of connecting the two units to-
gether.
NOTICE
The remote control setting must be
carried out on the controlling unit
In order for the remote control function
to work, the following steps must be
set on the controlling unit.
The controlling unit and the unit to be
controlled must be defined in advance.
6 | Remote control
Figure 14].
