Scope of delivery [
1 Base frame
3 Front panel
screw
5 Left side panel
7 Bracket for ex-
haust pipe
9 Exhaust pipe
1 Ethernet cable
1
Dimensions
Note that with a Combi-Duo system, the
connection heights and access heights
change for both units. You can find draw-
ings of the setup and precise dimensions
and height of the top rack rail for the dif-
ferent configurations in separate dimen-
sion drawings.
NOTICE! If the rack height is over 1600
mm [63 inches], affix the safety label to
the unit.
Key for dimension drawings:
1 Height of top
rack
3 Bottom unit ac-
cess height
5 Height of bottom
unit water drain
4

Preparations

Position the bottom unit
In order to position the bottom unit for the
Combi-Duo setup, mount the unit onto a
stand with feet, castors or a levelling kit.
14 / 100
Photo 01]
2 Insulation mat on
the right
4 Front panel
6 Insulation mat on
the left
8 Heat protection
cover for exhaust
pipe
1 Bracket
0
2 Top unit access
height
4 Height of top
unit water drain
80.51.370_iCombiPro-iCombiClassic_CD-E_IM_EU-west
Note that the distance X from the exhaust
pipe of the Combi-Duo unit is at least
10 mm [3/8 inch] to the wall.
X
If the exhaust pipe bracket is installed, this
corresponds to a flush-mounted installa-
tion.
Note the description in the unit's installa-
tion manual for positioning the unit on the
stand.
Align the bottom unit
Align the stand: Position the unit and
n
check the alignment with a spirit level
in the cooking cabinet. If necessary,
align the castors or feet evenly so that
the unit is standing securely.
Align the levelling kit: Align the level-
n
ling kit and check the alignment with a
spirit level before positioning the
lower unit on the levelling kit.
5

Installation

Removing the exhaust cover
DANGER
High voltages when connecting to the
mains power
Danger to life due to high voltage.
Disconnect from the power supply.
n
Make sure the unit is disconnected
n
from the power.
a
The unit is switched off and voltage-
free.
a
The electrical compartment is open.
4 | Preparations
