Exsys EX-41084 Anleitung

CONNECTORS & JUMPER SETTING
DB37F:
37 Pin Serial RS-232 Female Connector
Pin Signal Pin Signal
1 NC 14
2 DCD4 15
3 GND 16
4 CTS4 17
5 RXD4 18
6 RI3 19
7 DTR3 20
8 DSR3 21
9 RTS3 22
10 TXD3 23
11 DCD2 24
12 GND 25
13 CTS2 26
S1-S4_PWR:
S1-S4_PWR Jumper Setting
No Power Supplied on Pin1 or Pin9
5V P#1 12V P#9 5V
(Factory Setting)
DCD RI
5V P#1 12V P#9 5V
DCD RI
5V P#1 12V P#9 5V
DCD RI
5V P#1 12V P#9 5V
DCD RI
5V P#1 12V P#9 5V
DCD RI
5
HARDWARE INSTALLATION
If you are ready with the jumper settings, please proceed with the following installation instructions.
Because there are large differences between PC's, we can give you only a general installation
guide. Please refer to your computer's reference manual whenever in doubt.
Pin Signal 1. Turn off the power to your computer and any other connected peripherals.
RXD2 27 CTS3
2. Remove the mounting screws located at the rear and/ or sides panels of your Computer and
gently slide the cover off.
RI1 28 RXD3
DTR1 29 RI2
3. Locate an available PCI expansion slot and remove its covers from the rear panel of your
computer. Make sure it is the right PCI expansion slot for the card (see card description)
DSR1 30 DTR2
4. Align the card with the expansion slot, and then gently but firmly, insert the card. Make sure
RTS1 31 DSR2
the card is seated and oriented correctly. Never insert the card by force!
TXD1 32 RTS2
5. Then connect the card with a screw to the rear panel of the computer case.
RI4 33 TXD2
6. Gently replace your computer's cover and the mounting screws.
DTR4 34 DCD1
DSR4 35 GND
RTS4 36 CTS1
TXD4 37 RXD1 DRIVER INSTALLATION
DCD3
Windows
GND
After the hardware installation Windows will recognize the card automatically and install the
drivers. If the driver should not be installed automatically, please insert the Driver CD into your
CD-Rom drive (e.g. Drive D:) and open the folder „USB_to_IO/FTDI". Please select the folder
with your operating system and install the driver (see Picture). Follow the hardware assistant
and finish the installation. Important! Restart your PC in any case after installing the drivers.
Pin1= DCD
Pin9= RI
+5V to Pin1
CHECK INSTALLED DRIVER
+12V to Pin1
Open the >Device manager<. Now you should see at „Ports (COM & LPT)" and „USB-
Controller" the following new entry's:
+5V to Pin9
+12V to Pin9
If you see this or a similar information the device is installed correctly.
AUFBAU
S1-S4: 37 Pin Stecker zu
BESCHREIBUNG & TECHNISCHE DATEN
Die EX-41084 ist eine PCI serielle RS-232 Karte mit 4 seriellen FIFO 16C550 Ports, für den
Anschluss von High-Speed seriellen RS-232 Peripherie Geräten (z.B. Terminal, Modem, Plotter
usw.). Der serielle PCI Bus unterstützt dabei optimal die Leistung des schnellen FTDI Chipset.
Die Karte gewährleistet so eine sichere Datenübertragung und exzellente Performance von bis
zu 921.6KBaud/s! Sie unterstützt alle PCI & PCI-X Slots mit 3.3V und 5Volt. Es ist nicht möglich
die I/O Adressen und Interrupts manuell einzustellen, da die Einstellungen der Karte vom
System (BIOS) und vom Betriebssystem automatisch vorgenommen werden. Die EX-41084
bietet Ihnen die Möglichkeit, +5V und +12V auf Pin 1 und Pin 9 der seriellen Anschlüsse zur Verfü-
gung zu stellen.
Kompatibilität:
Betriebssysteme:
Anschlüsse:
Lieferumfang:
Zertifikate:
ANSCHLÜSSE & JUMPER EINSTELLUNG
DB 9M:
6
Anleitung
Vers. 1.0 / 19.06.19
S1~S4_PWR: Power auf Pin 1 oder Pin 9
4x 9Pin Serieller Anschluss
PCI & PCI-X, 5Volt oder 3,3Volt
Windows 9.x/ ME/ 2000/ XP/ Vista/ 7/ 8.x/ 10/ Server 20xx/ Linux/ MAC
4x 9 Pin D-Sub serieller Stecker
EX-41084, Oktopus Kabel, Treiber CD, Anleitung
9 Pin Stecker Seriell RS-232
Pin Signal Pin Signal
1 CDC 4 DTR
2 RXD 5 GND
3 TXD 6 DSR
1
EX-41084
des RS-232 Stecker Ein/Aus
Pin Signal
7 RTS
8 CTS
9 RI
