No. No. Adjusting point Adjusting point
21 Sample hold
pulse phase
checking
22 RGB tone
reproduction
adjustment
23 White balance
checking
24 Off-timer per-
formance
25 Thermistor
performance
checking
26 Auto sync
performance
checking
27 Delivery set-
tings
Adjusting conditions Adjusting conditions
1. Feed the SVGA 75-Hz
black signal.
2. Select the following group
and subjects.
Group : OUTPUT3
Subject : GCK-PHASE
RCK-PHASE
BCK-PHASE
1. Feed the SMPTE pattern
signal.
1. Use the adjustment condi-
tions in the item 10 for RGB
input and item 11 for sRGB
input.
1. Heat the thermistor with a
hair dryer.
1. Feed the phase check pat-
tern signal.
Adjusting procedure Adjusting procedure
1. Check the fixed value.
GCK-PHASE :282
RCK-PHASE :282
BCK-PHASE :282
1. Make sure the 100% and 95% white as well as the
0% and 5% black gradations are visible.
Check that there is no deviation of white balance with
the monitor.
1. Select OFF from the process mode.
Make sure the off-timer starts with 5 minutes
onscreen and count one minute in one second.
And then indication is 0 minute, the power supply
of the set is cut off.
1. Make sure that the temperature is indicated.
1. In the VGA, SVGA and XGA modes, make sure the
Clock, Phase, H-Pos and V-Pos settings can be au-
tomatically adjusted.
1. Make the following settings.
Process adjustment
SS3
29
PG-B10S
Remote control adjustment
Factory setting at 3
