3. USER INTERFACE
3.1 Local
3.1.1 Device Status
Note: The functions shown may vary based on the model or the access user level you use.
Key lock
Channel lock
USB flash drive / device connected
Timer record on
Overwrite on
Sequence mode on
PTZ mode on
Backup event queued and USB flash drive needed
CPU loading
Network Status:
(WAN) Internet connected
(WAN) Local connection
(LAN) Auto mode –Mbit/s
(LAN) DHCP / Static IP mode
3.1.2 Channel Status
Note: The functions shown may vary based on the model or the access user level you use.
Auto search on
Live audio on
Recording
Live information
Quick camera control
3.1.3 Quick Operation
Move to the arrow mark to extend the quick menu bar and show the four functions as follows:
Click to show the channel switch panel and select the channel you want.
Click to display the playback control panel, and click
list.
Click to open the IP search window and check the current connection status of each channel.
Click to show the power off panel to either halt or reboot the system.
