Connections

Connections
(4)
(5)
14
1
(2)
(3)
(4)
(5)
2
SpeedNet 1, process line 2 connection
For connecting to the wire buffer.
Connection using SpeedNet connection cable.
SpeedNet 2, process line 2 connection
(1) SpeedNet connection
For connecting to the power
source
Connection using SpeedNet
connection cable.
(1)
(2) SpeedNet 1, process line 1 con-
nection
For connecting to the SB 60i R.
Connection using SpeedNet ca-
ble from interconnecting ho-
sepack.
(3) SpeedNet 2, process line 1 con-
nection
For connecting to the unwin-
ding wirefeeder of process line
1.
Connection using SpeedNet
connection cable.
