Fronius OPT/i WireSwitch Installationsanleitung Seite 16

(13)
(14)
(15)
(16)
(17)
16
SplitBox SB 60i R
Always connect the SB 60i R to welding process line 1!
Welding process line 2 wirefeeding hose
Unwinding wirefeeder - wire buffer
Welding process line 1 wirefeeding hose
Unwinding wirefeeder - SB 60i
SpeedNet cable
Welding process line 2 unwinding wirefeeder control cable
SpeedNet cable
Welding process line 1 unwinding wirefeeder control cable
