10. Storage

The individual components such as ilter unit, exhaust arm and replacement parts have to be stored in their shipping boxes. Make sure,
that none of the components get damaged, if they are stored on top of each other. The storage space has to be dust free and protected
from moisture. The storage temperature should be between -10°C and +40°C and not fall below or exceed permanently.
Removed ilter material should not be stored, but disposed as soon as possible.

11. Emergency procedure

If the ilter unit or its components are on ire, proceed as explained in the following:
• If possible, disconnect the ilter unit by pulling the CEE plug.
• Fight a ire by ordinary powder extinguisher.
• If necessary, inform the local ire department.
Do not open the maintenance side door of the ilter unit, danger of explosives lames!
If the unit is on ire, only touch it with proper protective gloves, danger of getting burned!

12. Construction and spare parts*

Pos. Description
Pre-ilter mats (10 per set)
1
Main ilter
2
3 Control light, red
4 On / Off switch
5 Frontplatte red/yellow
Wheels set (1460226 roller ascertainable; 1460227 roller)
6/7
8 Ventilator motor
9 Impeller
10 Handle
Power cord + CEE plug
11
* Special equipment can come with different replacement parts. If you use a special unit, or if you are doubting, contact the SINOtec-service team.
26
Part no.
109 00 33
214 00
999 71 01 75
360 15 91
360 15 96
950 49 105
130 00 25
143 00 04
432 05
124 01 04
Fig. 5, construction
