8.2 Monthly inspection

Monthly inspection includes the measures as described under „Daily inspection" as well as the following measures.
Inspection task
Check the gaskets of the dust collection container and the ilter housing.
The yearly safety check as well as the maintenance has to be carried out by the SINOtec-service and not by the user. The control panel of
the ilter unit shows a message when the next service is necessary, be aware of that. Maintenance may only be carried out in a well-ventilated
and designated area, so that no individuals, which are not responsible for the maintenance, are harmed. During maintenance personal safety
equipment should be used, such as respiratory protection, protective glasses and gloves etc., in order to avoid contact with dangerous dust. The
inspection area has to be cleaned after the safety check.
Please keep the inspection date, which is indicated on the control panel.
Inform the SINOtec-service in time.

9. Technical data

The following technical information applies to the standard design. Special equipment can vary (see type plate).
Extraction capacity:
Power supply:
Motor performance:
Rated current:
Operation period:
Protection class:
Voltage:
Allowed surrounding temperature:
Noise level at a distance of 1 m at maximum air volume:
Dimensions (b x d x h):
Weight (without Extraction arm):
Extraction arm (diameter):
Extraction arm (length):
Procedure / Measures
Visual inspection, the gasket may have to be replaced.
1.200 m³/h
see type plate
see type plate
see type plate
100 %
IP 44
24 V
- 10 °C to + 40 °C
69 – 74 dB (A) DIN EN ISO 3744
655 x 655 x 1.020 mm
80 kg
150 mm
2,0 m / 3,0 m / 4,0 m
