How to replace a ilter:
• Turn off the power and unplug the device from the mains.
• Open the clamp fasteners on the housing cover.
• Tilt up the cover with one hand up while you support the exhaust arm with your free hand.
Tilt up the cover until the exhaust arm rests on the loor.
Caution! When the lid is opened with the exhaust arm mounted, under certain circumstances the device tends
to tip over. For this reason, we recommend changing the ilter using two people.
• Carefully remove the used pre-ilter mat without stirring up dust and fold it so that the ilter side that is full of dust particles is on the inside.
• Place the pre-ilter in a bag for disposal.
• Pull out the main ilter from the device and place it in a disposal bag. Here too, make sure that when changing the ilter, dust is not whirled up.
• Now place the new main ilter and the new pre-ilter mat into the device.
• Close the cover and fasten the clamps.
• Dispose of the used ilters according to oficial regulations. See also chapter 7.2.
Breathing in welding smoke particles, especially welding smoke particles from a welding process with alloyed steel
can damage health! Skin contact can result in skin irritation! Avoid eye contact with welding smoke particles.
Put on the respiratory protection, protective glasses and gloves.

7.2 Disposal information

The welding smoke/dust has to be stored and disposed according to the recycling management and waste act. Because of the different
composition of the welding smoke/dust you might have to ask the local disposal company, how to properly store and dispose your waste.
Description
Filter dust NE metalliferous
Main ilter with harmful pollution
(inorganic)

7.3 Disposal of device

The device must be disposed of without the ilter that is installed.
Before disposal of the device, the ilter must be removed in accordance with chapter 7.1 and must be specially disposed of in accordance with
the directives given in chapter 7.2.

8. Safety check

To ensure the optimal durable operation of the unit, the unit has to be maintained on a regular basis.

8.1 Daily inspection

Inspection task
Check the connected piping elements and hoses for leakage.
Check if the connection cable or the plug is damaged.
Check the sense of rotation of the fan if the position of the unit has
been changed.
Check if the ilter element is damaged.
24
Waste code Nature of waste
Dangerous conform the § 14 recycling
10 08 15
management and waste act.
Dangerous conform the § 14 recycling
15 02 02
management and waste act.
Procedure / Measures
Repair or replace the damaged parts.
Visual inspection, the connection cable or the plug may have to be
exchanged by an authorised electrician.
See chapter 4.1.
Observe the blow out opening on top of the ilter unit, when the ilter
unit is running. Check if there is any smoke leaving or if there is a lot
of dust settled. If so, the reason could be that the ilter is damaged,
which means that the welding smoke particles are not suficiently
iltered. Do not operate the unit in this case, since contaminated air
will enter the working area. This can lead to health damages.
Information
Disposal site for hazardous waste
Disposal site for hazardous waste
