1. General
See start of document.
2. Safety
See start of document.
3. Transport and interim storage
The pump may only be transported/suspended
on the handle provided for transport. It is
to be protected against humidity, frost and
mechanical damage.
4. Product and accessory description
4.1 Applications
Pumps for lifting of domestic waste water:
– sewage, rainwater containing sludge and parti-
cles (except rigid particles) with traces of hydro-
carbon, detergent.
– For fixed installation in a sump or a tank.
– For housing, garages, car-parks, restaurants,
boiler plants.
CAUTION! The pump must not be used for
pumping drinking water.
4.2 Description (see Fig. 1-2)
1 Check valve adapted to the conveyed medium
2 Isolating valve
3 Overflow audible signal
4 Pump lifting chain
5 Motor cable - length 5 m
6 Collector for twinned pump.
4.3 Description of pump
– Submersible monobloc electropump,
– Centrifugal single-stage with vortex impeller,
– Vertical discharge port,
– Tightness with mechanical seal and lip seal.
4.4 Description of motor
– Single-phase motor equipped with a built-in motor
cut-out, which switches the motor off if it over-
loads and automatically switches it back on again
once it has cooled down; delivered with electric
cable-length 5 m with a CEI 23-5 plug and float
switch.
Integrated capacitor.
– Protection index: IP68
– Insulation class: B
– Oil-cooled motor.
4.5 Products delivered
– Submersible motor-driven pump complete,
– Installation and operating instructions.
4.6 Accessories
Accessories must be ordered separately.
– Isolating valve,
– Non-return valve,
– Float switch,
– Lifting chain,
– switchbox for the automatic transmitter-
Installation and operating instructions - Wilo-Drain TC40
dependent control of one or two submersible
motor-driven pumps,
– Alarm switching device.
5. Product Information
Power consumption P1 [kW]
Motor-output P2 [kW]
Nominal current I 1~230 V [A]
Protection class at max. immersion depth
Insulation class
Immersion depth ( ) max. [m]
Temperature range [°C]
Max. particle size [mm]
Equipment
Cable type
Cable length [m] / plug
Float switch
Pressure support DN
Level control (Fig. 1, 2)
Shaft dimension min [mm]
Cut-out level continuous duty H1min [mm]
Cut-out level intermittent duty (short-term) Hmin [mm]
When ordering spare parts, please give all the
information on the pump rating plate.
6. Assembly/Installation
6.1 Installation
– Fig. 1: Installation of a pump with single-phase
motor, float switch and optional overflow audible
signal.
– Fig. 2: Fixed installation of 2 pumps connected
to a collector for twinned pumps and operating-
contol by 4 float switches.
NOTICE:
Cut-out level:
For intermitted duty:
H min = 40 mm short-term,
For continuous duty:
H1 min = 230 mm (Fig. 1-2)
The shaft should be of ample size, so that the
motor does not start too often.
NOTICE:
Lower the pump into the sump using a chain (or a
rope) hooked to the handle, never by its power-
or float switch cable.
Take care not to damage the power cable of the
motor during the going down in the sump.
Avoid placing the regulators near the outlet of
the pipe through which the water enters the
sump, since this could mover them.
Keep the lowest regulator away from the pump
suction port so that it will not be sucked in.
If the installation is outside protect the discharge
pipes, the isolating and check valve, and the elec-
tric controls from frost. Connect the cables to the
overload release or to the control box.
English
see rating plate
see rating plate
see rating plate
IP68
B
2
3 to 40
Ø 40
H07RN-F
5/Schuko (CEI 23-5)
connected
11/2"
450 x 450
230
40
25
