TER 1 B <cr>
TER FF X1 <cr>
TER FF X0 X0 <cr>
DENUM<cr> With this command the data chain will be completely rebuilt
NOT yet defined
With the new command set the data chain can consist of up to 99 Timys.
With the old command set the data chain can consist of up to 10 Timys.
With the new command set datas from eg. Timy 02 can be received.
If you want to control Timy 02 you can do it with TER02<command><cr>.
With the old command set it was much more complicate and depended from the length
of the data chain.
Answer from the data chain, when datas are sent.
TERMINAL
17
32
99
any
If a SLAVE of the running chain is missed, the this message is sent from the master to the pc:
TIMY<2 blanks><2digits NUMBER of the missed SLAVE><missing><cr>
Eg. "TIMY 04 missing<cr>"
If the missed SLAVE is reconnected or a further SLAVE is added,
then the MASTER sends this message to the pc:
TIMY<2 blanks><2digits NUMBER of the missed SLAVE><present><cr>
Eg. "TIMY 04 present<cr>"
2.6

Schnittstellendaten

RS 232 Schnittstelle
Standard 9600 Baud
8 Data Bit, no Parity Bit, 1 Stop Bit
ASCII Zeichen
2.7

RS232 Befehlssatz

Siehe Seiten 10 bis 11.
Timy Terminal
Message "Transmitting.." appears after the OK-button was pressed.
default: After OK-button was pressed, the screen remains unchanged
After an Timy-Update this feature is set to "X0".
3 C 123456
4 <D>
<Q>
< ' >
<special charactor of the ASCII set>
<"A" - 1 + any>
Beep for 0,1 s to Timy 1
03 123456
04 123456
17 123456
32 123456
Seite 10
syntax of the new format
only 1 to 9 with the
old format senceful
