Commands from the pc to the Master-Timy
Important: When the pc has sent a command to the Timy,
the pc has to wait for the exactly response of the sent command of the Timy
before it sends the next command.
Despite the Master-Timy may have sent some Datas in the meanwhile, the pc has still wait for
the response of the same command, which was sent before.
These commands are from an older pc-program. Addresses from 1 to 10
M R C <cr>
M A C <cr>
M R S <cr>
M C S <cr>
M R I <2 blanks> Hello Infotext<cr>
M D I <2 blanks> wrong Input<cr>
M R T 1
M E T 2
M R E R
M B E R
M R E I
M C E I
M R E C
M C E C
M R E S
M C E S
M R B <cr>
M A B <cr>
The blue commands are from a new pc-program. Addresses from 1 to 99
By using this syntax it is possible to control up to 99 SLAVES.
TER is the new command
Address is FF for all Timys or an 2 digit address
TER FF C <cr>
TER 01 C <cr>
TER FF S <cr>
TER 03 S <cr>
TER FF I <2 blanks> Hallo Infotext<cr>
TER 04 I <2 blanks> falsche Eingabe<cr>
TER FF T1A <max. 16 Zeichen><cr>
TER 05 T2I <max. 16 Zeichen><cr>
Timy Terminal
A <max. 16 characters><cr>
I <max. 16 characters><cr>
<cr>
<cr>
3 <cr>
3 <cr>
3 <cr>
3 <cr>
1 " 111 22 22 22<cr>"
2 " 111 22 22 22<cr>"
Stop
data insertion locked, no sending to pc allowed
Text to line (COMET: 1 or 2)
Seite 8
Version V 1.4
Clear
Stop
Info
Text
Reset
Init
Clear
Set
Set
Beep for 0,1 s
Beep for 0,1s to Timy A
Clear blocks are set to zero
messages from the pc are cleared
data insertion is possible
Info. In the uppermost line is the info-text.
In the lowest line is "GO ON WITH *"
(TIMY: 1 to 8 depends to the font)
from V 0971
