To optimise energy efficiency of the
building while preserving its occupants
comfort, the controller is scheduled
according to occupancy hours.
You can set the room occupancy
manually if the scheduled program does
not match the current occupancy status
of the room.
Occupied
For cassette fan coils with motorised
louvers, it is possible to control the
direction of the air flow by adjusting the
louver position.
1 to 6 fixed positions.
Automatic: Louver position is set
automatically.
Position 1 in Heating mode:
The heated air is directed to the floor
level.
Position 6 in Cooling mode:
The cooled air is distributed near the
ceiling.
Swing: Louvers keep oscillating from
the top downwards for better air
distribution.
4
All manuals and user guides at all-guides.com
Occupancy
Unoccupied
Louver Position
To set room occupancy
Press the Menu button
■
repeatedly until the Occupancy screen
appears.
Press the Up button
■
button
to set the room occupancy to
ON or OFF.
When the room occupancy is set, press
■
to go to the next screen or wait
10 seconds to go back to the default
screen.
To set the position of louvers
Press the Menu button
■
repeatedly until the Louver screen
appears.
Example:
Louver position: 1
Press the Up button
■
button to set the position of louvers.
Automatic
Fixed position (P1 to P6)
X
x = position number
Swing
When the louver position is set, press
■
to go to the next screen or wait
10 seconds to go back to the default screen.
Note: Louver position can be adjusted only
when the status of the room is occupied.
or the Down
Louver position:
Swing
or the Down
