6.4 Sound Control-Mode
The sound-control works via the built-in microphone.
Press the SOUND ACTIVE-button - the LED lites up red.
Push the Flash/Sensitivity-channel-fader to the desired sensitivity.
The Prog Select-channel-fader and the Speed-channel-fader are void in this mode.
6.5 Hold
Via this button, the Pause Function is set.
Press the HOLD-button - the LED lites up red.
You can activate the Pause Function in any mode.
6.6 Blackout-Mode
Press the BLACKOUT-button and all devices will be set to Blackout-mode.
The Blackout LED lites up yellow.
6.7 Zoom-Fader
With the Zoom-fader, you can adjust the beam angle of the lighting effect.
6.8 Channel switching
The controller can be switched from 6-channel-mode (Mode-LED off) to 4-channel-mode(Mode-LED on).
Press and hold the Mode-button until the Mode-LED is on. The controller now works in 4-channel-mode.
Make sure that the connected spot is set to 4-channel-mode and DMX starting address 1.
6.8 Channel-fader Parameters in the Internal Programs-Mode
R（PROG SELECT）
0-17
18-35 GREEN
36-53
54-71 YELLOW
72-89 PURPLE
90-107 CYAN
108-125 WHITE
126-143 THREE COLOR CHANGE
144-161 FIVE COLOR CHANGE
162-179 SEVEN COLOR CHANGE
180-197 COLOR DREAMING 1
198-215 COLOR DREAMING 2
216-233 COLOR DREAMING 3
234-251 AUTO RUN
252-255 SOUND ACTIVE
G（SPEED）
RED
BLUE
FUNCTION
Program
Running
Speed
0-255
(slowfast)
FUNCTION
B（FLASH/SENSITIVITY）
NO
Flash Speed
0 -10 OFF
11-255 (slowfast)
Sound-Active Sensitivity
NO
0 -7 OFF
8-255 (insensitivesensitive)
13/14
ZOOM
0-255 Zoom
00071074.DOC, Version 1.0
