4.2 Overview
Overview of the control elements
2
1. Color-buttons für SELECT-COLOR MODE
2. HOLD button
3. SELECT-COLOR MODE Button
4. PROGRAM SELECT MODE Button
5. PROGRAM SELECT channel fader
6. SPEED channel fader
7. FLASH FREQUENCY/SENSITIVITY channel fader
8. ZOOM fader
9. Microphone
10. BLACKOUT- Button
11. SOUND CONTROL Button
12. AUTO Button
13. MODE Button
Rear panel:
14. DMX Out
15. DC Input
1
3
4
5
13
3
8
6 7
14
11/14
9
