Instructions for installation and use

3. Parts list for Fuji Large

No. of Name
items
Base frame
1 Base frame, rear
2 Base frame
Wall elements
1 Electrical element W1
1 Electrical element W2
1 Ventilation element W3
1 Electrical element W4
1 Electrical element W5
1 Electrical element W6
1 Element above glass front, interior, black
1 Element above glass front, exterior, black
1 Mounting rail above door, black
Roof elements
1 Roof element D1
1 Roof element D2
1 Roof element D3
Corner posts
2 Corner posts
1 Corner post with groove for glass, black – left
1 Corner post with groove for glass, black – right
Support slats
2 Bench support slats
2 Bench support slats
1 Bench support slats
1 Bench support slats
p. 8/16
Dimensions (cm)
197.5 x 6 x 4
191 x 6 x 4
197.5 x 105.7 x 7.1
197.5 x 104.2 x 7.1
187.5 x 105.7 x 7.1
187.5 x 104.2 x 7.1
197.5 x 105.7 x 7.1
197.5 x 104.2 x 7.1
178.1 x 11 x 4.5
178.1 x 9.5 x 2.5
68.6 x 1.7 x 0.8
195.5 x 38.8 x 7.1
195.5 x 76 x 7.1
195.5 x 79.5 x 7.1
198.5 x 5 x 4
210 x 11.4 x 8
210 x 11.4 x 8
56 x 4 x 4
59.5 x 4 x 4
116 x 4 x 4
91.5 x 4 x 4
