6.8. Installing the electrical equipment
You need a hole in the cable shaft behind the heater measuring Ø 2 cm for the
heater supply cable. Use your vertical guideline (6.3.). Drill the cable outlet at a
right angle and route the cable as far as the roof to the power unit for the sauna
control (5 x 2.5 mm
combi and Home Premium combi).
Repeat for the heater sensor - Ø 1 cm, on the wall centrally above the heater -
15 cm below the ceiling.
Repeat for the bench sensor / humidity/temperature sensor - Ø 3 cm, opposite
the heater sensor on the wall - 15 cm below the ceiling.
You need a rectangular cutout for the control panel for the sauna control. You
can use the template to determine the position and size. Route the data cable
as far as the cabin roof to the power unit for the sauna control.
Observe the operating instructions for your sauna heater and the sau-
na control.
6.9. Installing accessories
The door handles are screwed together from the inside.
Fit the door magnet and sleeve plate. There are mounting holes under the seal
for the door magnet; the seal needs to be cut depending on how the door opens.
Position the floor grid.
6.10. Connecting the electrical equipment
ATTENTION!
Installation may only be performed by a qualified electrician or similarly
qualified person.
for Home fin and Home Premium fin / 7 x 2.5 mm
2
p. 14/16
for Home
2
